Red Bull Can Dimensions: A Complete Guide With Facts And Examples

A standard Red Bull can dimensions 250 ml (8.4 oz) can measures approximately 13.3–13.5 cm tall with a body diameter of 53–57 mm and a circumference of roughly 18 cm. The 355 ml (12 oz) can stands around 15.6 cm tall, the 473 ml (16 oz) reaches approximately 17.5–18 cm, and the 591 ml (20 oz) stands around 20 cm. All measurements may vary ±2 mm by production batch.

Key Takeaways

• Standard Red Bull 250 ml can: ~13.3–13.5 cm tall, 53–57 mm body diameter, ~18 cm circumference
• All four US sizes (250 ml, 355 ml, 473 ml, 591 ml) plus the European 500 ml covered with metric tables
• Measurements provided in centimetres and millimetres throughout
• Height discrepancies across online sources explained with a measurement variance note
• Real-world use cases: cup holder fit, fridge stacking, 3D design specs, cooler packing
• All measurements subject to ±1–2 mm manufacturing tolerance

How Tall Is a Red Bull Can in cm? — Understanding the Measurement Conflict

Before quoting a single number, it’s worth addressing why you’ll find different heights listed for the exact same can across different websites. The short answer: they’re measuring different things.

The 8.4 oz (250 ml) Red Bull can appears in sources ranging from 11.7 cm to 13.5 cm tall. This spread — nearly 2 cm — sounds alarming until you understand the three things people measure differently:

• Height to the seam/rim (the top curl of the can body, excluding the dome lid): approximately 11.5–11.7 cm
• Overall height including the lid dome (base to the flat top of the lid, excluding the pull ring): approximately 13.0–13.5 cm
• Absolute maximum height including the pull tab ring: approximately 13.8–14.0 cm

Most practical use cases — fitting in a cup holder, stacking in a fridge, designing packaging — use the overall height including the lid dome (measurement 2). That’s the figure we use throughout this article: approximately 13.3–13.5 cm for the 250 ml can.

A second source of variance is manufacturing tolerance. Aluminium beverage cans are produced on high-speed lines at rates of up to 1,500 cans per minute. Per industry standards documented by Beverage Can Makers Europe (BCME), dimensional tolerance across a production run is typically ±1–2 mm in height and ±0.5 mm in diameter.

Measurement Disclaimer:

All Red Bull can dimensions in this article represent standard production specifications. Actual cans may vary by ±1–2 mm in height and ±0.5 mm in diameter due to normal manufacturing tolerances. Measurements reflect overall can height including the lid dome, excluding the pull tab ring, unless otherwise noted.

Master Red Bull Can Dimensions Table — All Sizes in cm and mm

This is the reference table you need. All measurements are metric. Imperial equivalents are included for cross-reference only.

Note on the 250 ml body diameter: Multiple credible sources give values between 53 mm and 57 mm. The most commonly cited production spec for the European-standard 250 ml slim beverage can is 53 mm body diameter. For packaging and design purposes, use 53 mm body / 66 mm for 355 ml and larger.

Red Bull 250 ml Can Dimensions (Classic 8.4 oz Slim Can)

The 250 ml slim can is the format that launched Red Bull as a global brand. Dietrich Mateschitz and Chaleo Yoovidhya co-founded Red Bull GmbH in 1987, choosing the 250 ml European slim can format deliberately — it was compact, distinctive, and stood out against the wide-body 330–355 ml cans that dominated soft drinks at the time.

Measurements

What Makes This Size Unique

The 250 ml Red Bull can is the slimmest can in the mainstream energy drink category. Its 53 mm body diameter is narrower than the 66 mm used by 355 ml and 473 ml sizes. At 13.3–13.5 cm tall, it fits comfortably inside standard European kitchen cupboards, stacks two-high in most bar fridges, and slips into virtually every car cup holder on the market.

Best for: On-the-go single-serve use, gym bags, laptop bags, airline carry-on, desk storage, office fridges, gift packs, promotional display.

Red Bull 355 ml Can Dimensions (12 oz Tall Can)

The 355 ml (12 oz) Red Bull can is the standard North American single-serve size — matching the volume of a classic soda can. Red Bull introduced this format for the US market, where 355 ml is the most familiar beverage can volume.

Measurements

What Makes This Size Unique

At 66 mm wide, the 355 ml Red Bull transitions from the classic slim format to a standard-width beverage can. The 114 mg caffeine content makes this a popular choice for longer study sessions or pre-gym consumption. Despite being 43% larger in volume, the 66 mm diameter still fits comfortably in the EU’s standard 74–84 mm cup holders.

Best for: Study sessions, moderate physical activity, US market standard use, convenience stores, gym coolers.

Red Bull 473 ml Can Dimensions (16 oz Tallboy)

The 473 ml (16 oz) tallboy is Red Bull’s largest slim-format can and the fastest-growing size segment in the US energy drink market. It delivers 151 mg of caffeine — nearly double the classic can — in a package that most cup holders can still accommodate.

Measurements

What Makes This Size Unique

At 17.5–18 cm tall, the 473 ml can is the tallest Red Bull format still commonly found in standard retail settings. The diameter holds at 66–67 mm — the same as the 355 ml — meaning the two cans are interchangeable in cup holders, vending machine coils, and retail shelf facings.

Best for: Long drives, extended work sessions, high-intensity sport, warehouse clubs, bulk retail.

Red Bull 591 ml Can Dimensions (20 oz King Size)

The 591 ml (20 oz) Red Bull can is the largest commonly available size in the US market. It uses a wider body to accommodate the additional volume, making it the only Red Bull format that noticeably differs from the slim aesthetic of the smaller sizes.

Measurements

What Makes This Size Unique

The 591 ml can’s 80 mm body diameter is the significant departure from the Red Bull family. This is the only Red Bull can that approaches the wide-body format used by Monster Energy and Rockstar at 16 oz. At 80 mm, it is wider than most standard EU car cup holders (74–84 mm) — a tight fit in some vehicles.

Best for: Gaming sessions, very long drives, value-focused purchasers, petrol station coolers.

Red Bull 500 ml Can Dimensions (European Format)

The 500 ml Red Bull can is primarily sold in European markets and some Asian markets. It is taller than any US format, using the same 66 mm body diameter as the 355 ml and 473 ml US cans, achieving the additional volume through increased height rather than a wider body.

Measurements

This is the tallest format in the Red Bull portfolio. At 22.3 cm, it exceeds the internal height of many mini-bar refrigerators (typically 20–22 cm shelf-to-shelf clearance) and may require positioning on the bottom shelf or door compartment.

Best for: European on-the-go use, convenience stores, cafés, petrol stations across EU markets.

How Do Red Bull Can Sizes Compare to Other Energy Drinks?

One of the most common reasons people search for Red Bull can dimensions is to compare them with Monster, Celsius, Rockstar, or Bang. Here’s how they stack up, all in metric.

Key takeaway: Red Bull’s 250 ml classic can is uniquely slim — its 53 mm diameter is narrower than any other mainstream energy drink can. All 355 ml and larger Red Bull cans use the same 66 mm standard can diameter as most soda brands, distinguishing them from Monster, Rockstar, and Bang’s 68 mm wide-body format.

Does a Red Bull Can Fit in a Standard Car Cup Holder?

Cup Holder Fit Guide (metric)

Tip: For the classic 250 ml slim can in a wide cup holder, consider using a can sleeve or adaptor insert — the 21 mm gap means the can will tip and rattle at speed. The 355 ml and 473 ml cans are the most stable in standard cup holders without any adaptor.

Practical Use Cases: Fridge Storage, Cooler Packing & Design Projects

Fridge Storage (metric)

A standard under-counter kitchen fridge shelf is typically 500–550 mm wide and 300–400 mm deep.

Stacking: Aluminium cans are not designed to be stacked vertically beyond one layer without a rack. Use a purpose-built can organiser for multi-row storage.

Cooler Packing

A standard 30-litre camping cooler (internal footprint approximately 400 × 250 mm) holds:

• 250 ml cans standing upright: approximately 28 cans (7 × 4) per layer
• 355 ml / 473 ml cans standing upright: approximately 24 cans (6 × 4) per layer

3D Design and Packaging Projects (mm specifications)

For 3D models, product renders, and packaging mockups, use these precise mm values:

All Red Bull aluminium cans use a wall thickness of approximately 0.25 mm — consistent with industry-standard food-grade aluminium alloy (typically 3004-H19 or equivalent).

How to Measure a Red Bull Can Yourself (Metric Method)

Tools You’ll Need

• A calliper (digital preferred, accurate to 0.1 mm) — best for diameter
• A flexible tape measure — for circumference
• A straight ruler or flat surface — for height

Step-by-Step

1. Measure the height — Stand the can on a flat surface. Place a ruler vertically against the body. Read from the base to the top of the flat lid surface (not the pull ring).
2. Measure the body diameter — Use a calliper at the straight-walled section of the can body (roughly the middle third), away from the tapered neck.
3. Measure the circumference — Wrap a flexible tape measure around the widest point of the can body. You can cross-check: circumference = π × diameter.

Common Mistakes to Avoid

• Including the pull tab in the height measurement — adds 8–12 mm and isn’t a useful functional measurement
• Measuring at the neck — always measure the straight wall
• Assuming all cans of the same volume are identical — regional and seasonal production variants can differ by 1–2 mm

Why Are Red Bull Cans Shaped the Way They Are? Engineering and Design

The 250 ml Slim Can: A Brand Identity Decision

When Dietrich Mateschitz designed the Red Bull product for the European market in 1987, he chose the 250 ml slim format. Most soft drinks of the era used 330 ml or 355 ml wide-body cans. The Red Bull can’s 53 mm diameter made it immediately visually distinctive on any shelf — a silent signal of premium, concentrated energy rather than bulk refreshment.

Why Slim Cans Use Less Aluminium for the Same Volume

A 250 ml slim can (53 mm × ~133 mm) has a surface area of approximately 266 cm². A hypothetical 250 ml wide-body can (66 mm diameter × ~73 mm tall) would have a surface area of approximately 186 cm² — significantly less metal, but a completely different visual footprint. Red Bull chose height over width, accepting slightly more material use in exchange for shelf presence and ergonomic distinctiveness.

Wall Thickness: Strong by Design

Red Bull cans use approximately 0.25 mm wall thickness — less than three sheets of standard printer paper. This is made possible by the cylindrical pressure vessel design: when a carbonated can is sealed, internal CO2 pressure (approximately 3–4 bar) creates hoop stress that stiffens the can walls dramatically. A sealed aluminium can can support the weight of a person standing on it.

International Red Bull Can Size Variants

Note on the 32 oz / 946 ml Red Bull Refresher: Some US wholesale retailers stock a 32 oz (946 ml) format. Dimensions for this rare size are approximately 26–28 cm tall with a ~84 mm body diameter. This format is not widely stocked and measurements are not consistently documented.

Conclusion

Red Bull can dimensions are more nuanced than most measurement guides acknowledge. The classic 250 ml can stands 13.3–13.5 cm tall with a 53 mm body diameter — a slim, distinctive format that launched an industry. The 355 ml and 473 ml cans share a wider 66 mm body and range from 15.6 to 18 cm tall. The 591 ml king-size steps up to ~80 mm wide and ~20 cm tall — the only Red Bull format that challenges standard cup holder clearance.
